規格描述
SOLDERING: DIP
POLE-POSITION: 2P2T
RATING: DC 50V 0.3A
OPERATING FORCE: 250±100gf
OPERATING LIFE: 10,000CYCLES
CONTACT RESISTANCE: 30mΩ max
INSULATION RESISTANCE: Min. 100MΩ
DIELECTRIC STRENGTH: AC50 V for 1 minute
OPERATING TEMPERATURE RANGE: -16°C~+60°C
