規格描述
SOLDERING: DIP
POLE-POSITION: 1P2T
RATING: DC 10V 0.3A
OPERATING FORCE: 100~300gf
OPERATING LIFE: 10,000CYCLES
CONTACT RESISTANCE:50mΩ max
INSULATION RESISTANCE: Min. 100MΩ
DIELECTRIC STRENGTH: AC 500V for 1 minute
OPERATING TEMPERATURE RANGE: -10°C~+60°C
