SOLDERING : SMD RATINGS : DC15V 20mA OPERATING LIFE : 200,000 Cycles OPERATING FORCE : (N)160±50gf OPERATING TEMPERATURE : -40 ~ 85 ℃ CONTACT RESISTANCE : 100mΩ Max. INSULATION RESISTANCE : 100MΩ Min. VOLTAGE PROOF : AC250V 1Min
