SOLDERING : SMD RATINGS : DC30V 0.1A OPERATING LIFE : 100,000 Cycles OPERATING FORCE :0.3N max. OPERATING TEMPERATURE : -10 ~ 60℃ CONTACT RESISTANCE : 1Ω max. INSULATION RESISTANCE : 100MΩ Min. VOLTAGE PROOF : AC100V 1Min
