SOLDERING : DIP RATINGS : DC12V 1A OPERATING LIFE : 10,000 Cycles OPERATING FORCE : 250±100gf OPERATING TEMPERATURE : -25℃~+70℃ CONTACT RESISTANCE : 30mΩ Max. INSULATION RESISTANCE : 100MΩ Min. DIELECTRIC STRENGTH : AC500V 1Min
