SOLDERING : DIP RATINGS : DC 50V 0.3A OPERATING LIFE : 50,000 Cycles OPERATING FORCE : 40gf ±10gf OPERATING TEMPERATURE : -20℃~+60℃ CONTACT RESISTANCE : 50mΩ Max. INSULATION RESISTANCE : 100MΩ Min. VOLTAGE PROOF : AC500V 1Min
